Electricity: 5kVA/ 380V/50Hz /3-phase
Other required numbers Fuse: 16 Amp inert
Air source: 201/min. 6 bars
Diameter range: 125 -1250 mm
Maximum arc angle: 30°. (4 parts 90° bending)
Material thickness: galvanized sheet 0.4-1.5 mm
Stainless steel 0.4-1.0 mm
Aluminum 0.4-1.5 mm
Copper 0.4-125 mm
All materials must be formed by locking.
Flange height: 5/7.5/ 10 mm
Recommended range: 5 mm  φ 250 mm
7. 5mm  φ250~500mm
10mm φ500~1250mm
Peripheral speed: 0-120m/minute. Continuous
Length without support arm: 2687mm
Width without support arm: 817mm
Height: 1086mm
Machine net weight: 775 kg
Packing size: L/B/H = 2830/920/1540 mm
Hydraulic oil quality:46 cST
Oil capacity: 65 litres
Optional machine: can be used for 3 sections of 90° bending
